QYM-WELDED MESH FENCE

QYM-WELDED MESH FENCE

All Age Groups

All Purpose Use

SKU: N/A

Categories: Fences, Fences for Parks, Fences for Villas, Sports Area Fences

QYM-Welded mesh fence

As an economical type of panel system, a welded mesh fence is a kind of 3D fence with longitudinal folds, which makes the fence stronger. The fence panel is welded by high-quality low carbon steel wire. Its common surface treatments are hot-dipped galvanized or electrostatic polyester powder spray coating over galvanized wire.

The common post of this fence is SHS tube, RHS tube, Peach post, Round pipe, or Special-shaped post. The fence panel will be fixed to the post by suitable clips according to different post types.

Due to its simple structure, see-through panel, easy installation, nice appearance, the welded mesh fence is more and more popular.

Description

Product Features:

Low cost, easy installation
10-Year limited warranty
Galvanized steel components
Suitable to all kinds of surrounding
Panels mounted inside post or on postface
The durable polyester powder coating finish

Specification:

For post:

Round post,

Size: 48mm, 60mm

Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm

Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

Square post:

Size: 50mmx50mm, 60mmx60mm,

Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm

Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

Rectangular post:

Size: 40mmx60mm, 40mmx80mm,

Thickness: 1.5mm, 2.0mm, 2.5mm, 3.0mm

Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

Peach post:

Size: 50mmx70mm, 70mmx100mm,

Thickness: 1.2mm, 1.5mm,

Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

I post:

Size: 42mmx70mm,

Thickness: 1.2mm, 1.5mm, 2.0mm

Height: 1.4m, 1.6m, 1.8m, 2.0m, 2.3m, 2.5m, 2.8m, 3m

For panels:

Height: 1.03m, 1.23m, 1.43m, 1.63m, 1.83m, 2.03m, 2.23m, 2.43m.

Width: 2.0m, 2.5m, 2.9m.

Wire thickness: 3.0mm, 3.5mm 4.0mm, 4.5mm, 5.0mm

Spacing between horizontal wire: 100mm, 150mm, 200mm.

Spacing between vertical wire: 50mm, 55mm.

Reforced folds: 100mm, 200mm.
